Battery compatibility
Chemistry changes the series range
- Li-ion (ternary/NMC)
- 7–24S
- LiFePO4 (LFP)
- 8–24S
- Lithium titanate (LTO)
- 14–24S
1 / 1Product-family image. Exact SKU appearance and supplied items are not confirmed by this image.
JKBMS JK-B1A / B2A Series
JK-B2A24S30P
JK-B2A24S30P
JK-B2A24S30P supports 7-24S Li-ion, 8-24S LiFePO4 and 14-24S LTO packs. The V19.0.2 manual lists 300 A maximum charge and discharge current, 600 A instantaneous current and 2 A active balancing. Bluetooth, UART and display are standard; CAN, RS485, heating, alarm, parallel and ACC functions are optional and must be confirmed in the order.
BMS selectorChoose configuration
Selected configuration$174.98
Shipping is calculated by destination during checkout. PayPal verifies and captures the final amount securely.
Selected SKU facts
- Selected model
- JK-B2A24S30P
- Configuration
- JK-B2A24S30P
- Technical status
- Documented model; confirm shipped revision
- Battery chemistry / strings
- Li-ion (ternary/NMC): 7-24S; LiFePO4 (LFP): 8-24S; Lithium titanate (LTO): 14-24S
- Continuous discharge
- Unknown - factory confirmation required
- Maximum discharge (not continuous)
- 300 A
- Maximum charge
- 300 A
- Active balance
- 2 A
- Documented standard interfaces
- Bluetooth, UART, display interface
- Optional; not confirmed on this SKU
- CAN, RS485, heating control, alarm output, parallel interface, ACC
- Manual basis
- V19.0.2
Manual maximum values require suitable conductors, terminals, fusing, cooling and battery cells.
Manual data is revision-specific. Confirm the shipped label and harness before wiring.
Optional compatible accessories
No confirmed accessory match for this configuration. Request compatibility confirmation.
MANUAL-VERIFIED TECHNICAL REFERENCE
JK-B2A24S30P data by hardware revision
The V19.0.2 manual verifies chemistry-specific 7-24S/8-24S/14-24S limits, 300 A maximum charge and discharge current, 2 A active balancing, operating limits and mechanical data. Wired communication remains configuration-dependent.
Electrical limits
Use the correct rating label
- Active balance
- 2 A
- Maximum charge
- 300 A
- Maximum discharge
- 300 A
- Instantaneous current
- 600 A
- Supply voltage
- 20–100 V
- Cell-voltage accuracy
- ±3 mV
Manual maximum values require suitable conductors, terminals, fusing, cooling and battery cells.
Interfaces and functions
Standard is not the same as optional
Standard
Bluetooth · UART · display interface
Optional / suffix-dependent
CAN · RS485 · heating control · alarm output · parallel interface · ACC
- CAN and RS485 are optional and must be present in the ordered configuration.
- A physical CAN or RS485 port does not by itself confirm inverter protocol compatibility.
Mechanical and environment
Match dimensions to the label
- V19.0.2
- 208 × 120.7 × 15.6 mm · 675 g
- Operating temperature
- -30°C to 70°C
- Maximum operating power
- 1.2 W
Revision control matters.
- V19.0.2 is the newest applicable revision located in the verified package; this does not by itself prove the current shipment revision.
- Confirm the shipped label and communication suffix before using the manual's connector definitions.
Manual basis
Documents reviewed for this page
- JK-B2A24S-30P User Manual V19.0.2Reviewed pages: 4, 8-9, 17, 21-25
Before ordering
Four details that prevent the wrong configuration
- Confirm battery chemistry and exact series count.
- Confirm the expected charge/discharge duty, cable size, terminals, fuse and cooling.
- State whether CAN, RS485, heating, alarm, parallel interface or ACC is required.
- Provide the inverter brand/model and confirm protocol, firmware, cable and pinout before shipment.
Product details
Supply scope and specifications
Key features
- Chemistry-specific support: 7-24S Li-ion, 8-24S LiFePO4, 14-24S LTO
- Maximum charge/discharge current: 300 A; instantaneous current: 600 A
- 2 A active cell balancing and ±3 mV cell-voltage accuracy
- Standard interfaces: Bluetooth, UART and display
- Optional by configuration: CAN, RS485, heating, alarm, parallel interface and ACC
- V19.0.2 mechanical reference: 208 × 120.7 × 15.6 mm, 675 g
Included
- Selected configuration: JK-B2A24S30P
- Exact harness and supplied items require confirmation against the packing list.
Not included
- Battery cells, battery enclosure, inverter, charger, and external power cabling
- External contactors, breakers, fuses, and installation hardware unless specified
- Onsite installation, commissioning, firmware setup, or inverter configuration service
Selected modelJK-B2A24S30P
ConfigurationJK-B2A24S30P
Technical statusDocumented model; confirm shipped revision
Battery chemistry / stringsLi-ion (ternary/NMC): 7-24S; LiFePO4 (LFP): 8-24S; Lithium titanate (LTO): 14-24S
Continuous dischargeUnknown - factory confirmation required
Maximum discharge (not continuous)300 A
Maximum charge300 A
Active balance2 A
Documented standard interfacesBluetooth, UART, display interface
Optional; not confirmed on this SKUCAN, RS485, heating control, alarm output, parallel interface, ACC
Manual basisV19.0.2
Exact-model verification
JKBMS JK-B2A24S-30P user manual V19.0.2
